LOW CURRENT FILTERS
Serie: FLCS
Capacitive/inductive filter, general purpose, reduced footprint
ELECTRICAL CHARACTERISTICS
Value range
0,68MΩ ≤ R ≤ 10MΩ
0,1 μF ≤ CX = 0,33 μF
0,47 nF ≤ CY ≤ 10nF
0,5mH ≤ L ≤ 40 mH
Rated voltage (VR)
250V
Rated current (IR) @ 40°C
0,5A ≤ I ≤ 7A
Mounting
M8 threaded stud
MECHANICAL CHARACTERISTICS
Housing
Plastic housing 38×28 mm
Terminals
Faston
ELECTRICAL DESIGN
MECHANICAL DESIGN
